- Auto Leveling
- Realizing one-touch leveling and printing.

- Fast Assembly
- Integrated structure.

- Large-size Touch Screen
- New UI, Easy to operate.

- Stepper Drivers
- Silent printing.
Technical Specifications
- Printing Technology: FDM (Fused Deposition Modeling)
- Build Volume: 245mm(L)×245(W)×260mm(H)
- Print resolution : ±0.1mm
- Positioning accuracy: X/Y 0.0125mm; Z 0.002mm
- Extruder number: Single; Nozzle diameter: 0.4 mm
- Print Speed: ≤ 180mm/s (recommended 80mm/s)
- Support filaments: PLA, TPU, ABS, PETG, Wood
- Ambient Operating Temperature: 8°C - 40°C
- Operational Nozzle Temperature: max ≤260°C
- Operational Hot Bed Temperature: max ≤110°C
- Slicing Software: Cura; Output Formats: GCode
- Input Formats: .STL, .OBJ, .AMF
- Connection mode: Trans-flash Card; USB cable(expert users only)
- Input voltage: 100V/240V AC, 60/50Hz
- Output voltage: 24V/14.6A(350W)
- Machine size: 508mm×457mm×516mm
- Machine weight: ~10kg

- Auto Leveling
- Don't need manual leveling, the intelligent leveling system can automatically adjust the uneven hotbed. Precise pressure strain gauge,16-point precise leveling.

- High-precision double screw
- The machine’s double screw runs synchronously, thus bringing more stable operation and smaller zeroing error.

- Double photoelectric limit
- The machine can automatically compensate the difference of the hot bed to make Z-axis zeroing more accurate.

- Spring steel magnetic platform
- High toughness; Scratch-resistant coating; Easy model removal. It is compatible with a wide range of filaments.

- Dual cooling Fans
- The printing head adopts a double fan two-way heat dissipation system, cools down models rapidly. The printing speed is faster which can reach 180mm/s, based on the test results of Anycubic lab.(average speed is 80mm/s)

- Double-gear extrusion system
- The extrusion system is able to reduce the chances of filament tangle and is compatible with PLA & flexible filaments. Strong extrusion force; Path optimization.

- Small body and big size
- With 245 * 245 * 260mm print size, the printer can meet your endless creative needs.

- 4.3" large-size touch screen
- The screen features new UI interface, smooth and simple operation as well as English and Chinese switching. New UI; Large-size screen; Easy to operate.

- A brand-new core
- M3 chip; High-speed computing; Silent printing; 32-bit main frequency: 72M; 8-bit main frequency: 16M.
Parts List

Display Screen

Filament

Filament-holder

Nozzle

Power cord

Screw(M5)-*14 3pcs

Screw(M5)-*45 4pcs

SD Card

Service Card

SD Card-Reader

User Manual
