Guides

The ZD420 Series printer detect automatically media type (gap, notch or black mark) and dimensions using special sensors  We will explain you how to calibrate ZD420 Printers Make sure that the media and ribbon cartridge (if printing in thermal transfer mode) are properly loaded in the printer and that the top cover of the printer is closed. Press the POWER button to turn on the printer When the printer is ready, press and hold the PAUSE and CANCEL buttons for two (2) seconds, then release them. Refer to the following image: The printer will measure some labels and adjust the media...

Download Drivers Windows Mac

Download Drivers Windows

How-to Videos for reference here Install the latest Zebra Driver Installation package from the link here When specifying the computer port, select the “USB” option. When selecting the printer, Please Select ZDesigner ZD230 or Look for your Zebra model otherwise.   Setting the default Label Size for Shipping Labels You can download the Label setting here and use it directly or follow the steps below. Select Configure Print Settings in Zebra Setup Utilities, Set Label size accordingly Zebra Shipping Label 102mm x 152mm (4” x 6”) Kingly Shipping Label 100mm x 150mm Print mode: DirectMedia Type: Web Sensing   For Mac Setup...

The difference types of barcodes available
